Square Trimless Fixed recessed downlight designed to deliver clean, uniform illumination with a seamless architectural appearance. As its name implies, this is an immovable light. Directed downward, the angle and size is based on the angle of the beam within its globe. Super easy to install, this option provides even illumination and makes this the common favorite for general lighting
General Specifications
- FIXTURE BODY 18 gauge powder coated steel body. Aluminum powder coated trim or trimless mesh plate
- INSTALLATON TYPE Remodel/existing ceiling N/C plate, IC Box on page 2
- CUT HOLE Trim & Trimless: 4 1/8" x 4 1/8"
- COLOR FINISH Black/White/Custom
- LIGHT MODULE High output, high efficiency
- LED COB Lumen Maintenance: 70%@50,000 hrs
- INPUT VOLTAGE 120V - 277V
- WATTAGE 10W IC Rated, 15W Non-IC Rated
- POWER SUPPLY ERP 10W or 15W, Constant Current 250mA or 350mA power supply Minimum operating temperature: -30o Enclosed in a Junction box with 12” flexible cable to mate to module connector
- CRI 90+
- DIMMING TRIAC/ELV/0-10V
- DELIVERED LUMENS 10W IC: 810 LM, 10H IC: 1090 LM, 15W Non-IC: 1430 LM, Dim to Warm: 15W, 785 LM
- CCT OPTIONS 2700K/3000K/3500K/4000K, DTM (Dim to warm)
- REFLECTORS (N) Narrow 15o/(M) Medium 24o/(W) Wide 38o/ (F) Flood Wide 50o
- DIFFUSERS (CL) Clear/(LN) Linear Spread/(FR) Frosted (SP) Solite/(HC)Honeycomb Louvre
- APPROVAL Wet
Trimless Fixed Downlight Bravo Recessed
$266.00Price
